Pulper

High Density Hydrapulper System

DESCRIPTION

High Density / Consistency Hydrapulper
It is suitable for waste paper slurry consistency of 10-18% and Volume of 0-50m3. This Hydrapulper is to separate fiber, purification of the thick liquid material, and select thickly Pulping Equipment, can be continuous or intermittent treated with various different pulp, semi-chemical pulp, pulp board (meal), goods wasted paper, and so on.

Feature of hydrapulper :
1. The conical screw Rotor of Hydrapulper has a strong defibering capacity on the pulp stock without damaging impurities;
2. This Hydrapulper has a higher concentration in the processed pulp stock (12%-18%), saving energy and chemical medicines;
3. Hydrapulper has a compact structure and is easy to operate and maintain.

Main Technical Parameters:

Type	HT-1	HT-2	HT-3	HT-4	HT-5	HT-6	HT-7	HT-8	HT-9	HT-10	HT-11	HT-12
Normal volume: m3	2.5	5	8	10	15	20	25	30	35	40	45	50
Treating density: %	10 -- 15 %
Capacity of product: t/d	7-10	20-25	30-35	40-50	60-70	80-100	130-185	160-225	185-260	210-295	235-330	230-360
Power of motor: kw	55	110	185	220	310	400	450	500	560	630	710	800
