Pulper

Low Density D Hydrapulper

DESCRIPTION

Application:
Used in the paper and pulp industry for breaking waste paper and wet-strength paper. This equipment is fitted with P.S. Vokes rotor,
which can strengthen the hydraulic cycle and fiber defiberizing and also perform continuous breaking with lower energy consumption.

The rotor deviates from the center of the trough body and the trough body structure is D-shape, which can make the contact between pulp and rotor quicker, with higher frequency. Thereby, on the condition of not increasing power and volume, capacity can be increased. The rotor and extraction disc are above the bottom plane of the trough body, thus, one low-pressure flow area can form around the rotor to gather heavy impurities, thereby the service life of rotor and extraction plate can be extended.

Main Technical Parameters：

Type	HT-25	HT-26	HT-27	HT-28	HT-29	HT-30	HT-31	HT-32	HT-33	HT-34	HT-35	HT-36	HT-37
Volume: m3	15	20	25	30	35	40	45	50	60	70	80	100	130
Density: %	3 -- 5
Capacity: t/d	80-120	140-180	180-230	230-280	270-320	300-370	350-400	400-450	480-550	550-630	600-700	750-850	950-1050
Motor: kw	160	185	220	280	315	355	400	450	560	630	710	900	1000
