Screening and Cleaning

Heavey Reject Cleaner

DESCRIPTION

Heavey Reject Cleaner

Application:
HT-1000 Low Consistency Cleaner is suitable for cleaning various kinds of pulp with a consistency of 1.6%-1.2%.

Design Features:
The working consistency of the Low Consistency Cleaner is as high as 2.5%, hence the number of cleaners is reduced accordingly. It is suitable for meeting the requirements of high capacity pulp making equipment.
The bottom part is equipped with an axial flushing water device, it can control the coarse rejects consistency individually and control the fiber loss efficiently.
By diluting the coarse rejects, there will no appear blocking phenomenon in the pro- cess of reject discharging in every stage.

Main Technical Parameters:

Throughput	Working Density	First Stage Inlet Pressure	Second Stage Inlet Pressure	Third Stage Inlet Pressure	Reject By Solid	Reject By Volume
1000l/min	1.5-2.5%	300-320KPa	280-300KPa	250-280KPa	15-25%	10-12%
