Paper Machine Pope Reel

Paper Machine Pope Reel Introduction
This machine is used for the first set of finishing equipment behind the paper machine. The roll cylinder is operated actively, and the roll is driven by friction to complete the paper winding. By adjusting the pressure of the auxiliary arm and the cylinder of the main arm to adjust the linear pressure between the roll and the cylinder, the operation can meet the needs of different kinds of paper and make the paper rolled down from the paper machine into a compact and uniform roll paper.

Technical details of Pope Reel:
Net paper width: 1092-5600
Working speed(m/min): Customization
Driving Method: Unified arrangement with paper machine drive
GSM: 15-360 GSM
Max Jumbo roll diameter: 2800mm

Working theory of Horizontal pneumatical Pope reel:
The winding roller is driven to wind paper by a cooling drum, the cooling cylinder is equipped with a driving motor. In working, the linear pressure between the paper roll and cooling drum can be adjusted by controlling the air pressure of the main arm and vice arm air cylinder.

Feature:
high working speed,no-stop, save paper, shorten paper roll changing time, neat tight big paper roll, high efficiency, easy operation.
